How to use ElevenLabs text-to-speech in Unity

A simple script to add ElevenLabs text-to-speech to your Unity game.

Calculon from Futurama sipping cognac or whatever.

As you probably know, I work for a company developing conversational UIs. During the last few months, we had several demos of interactive applications and games focused on user interaction with virtual avatars. Text-to-Speech (TTS) is a fundamental aspect of such applications: nothing destroys the illusion of a virtual character more than a robotic and artificial voice.

For this reason, I ended up trying several text-to-speech services, looking for the perfect one. I had two requirements: 1) I wanted a realistic voice, and 2) I didn’t want to mess with manually tagging and tuning the vocal emotions of a text (in fact, it is hard to do if part of the voiced text is itself mildly-generated by AI).

Luckily, we live in a booming age of AI services, so I had many options to choose from (and new services are popping up every day).

At the moment I am writing (August 2023), I concluded that the best TTS service is the one provided by ElevenLabs. It is a bit expensive, but the voices are very natural, and it is easy to get high-quality results by just typing the text. The only problem is that ElevenLabs does not offer a Unity SDK, so I had to write a simple script for my Unity projects.

In the spirit of collaboration, I decided to share the basic version of my script. It is not perfect and could use some stronger input sanitization, but it works and is a good starting point if you want to add ElevenLabs TTS to your Unity project.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
using System;
using System.Collections;
using System.Text;
using Newtonsoft.Json;
using UnityEngine;
using UnityEngine.Events;
using UnityEngine.Networking;

public class ElevenlabsAPI : MonoBehaviour {
    [SerializeField]
    private string _voiceId;
    [SerializeField]
    private string _apiKey;
    [SerializeField]
    private string _apiUrl = "https://api.elevenlabs.io";

    private AudioClip _audioClip;

    // If true, the audio will be streamed instead of downloaded
    // Unfortunately, Unity has some problems with streaming audio
    // but I left this option here in case you want to try it.
    public bool Streaming;

    [Range(0, 4)]
    public int LatencyOptimization;

    // This event is used to broadcast the received AudioClip
    public UnityEvent<AudioClip> AudioReceived;

    public ElevenlabsAPI(string apiKey, string voiceId) {
        _apiKey = apiKey;
        _voiceId = voiceId;
    }

    public void GetAudio(string text) {
        StartCoroutine(DoRequest(text));
    }

    IEnumerator DoRequest(string message) {
        var postData = new TextToSpeechRequest {
            text = message,
            model_id = "eleven_monolingual_v1"
        };

        // TODO: This could be easily exposed in the Unity inspector,
        // but I had no use for it in my work demo.
        var voiceSetting = new VoiceSettings {
            stability = 0,
            similarity_boost = 0,
            style = 0.5f,
            use_speaker_boost = true
        };
        postData.voice_settings = voiceSetting;
        var json = JsonConvert.SerializeObject(postData);
        var uH = new UploadHandlerRaw(Encoding.ASCII.GetBytes(json));
        var stream = (Streaming) ? "/stream" : "";
        var url = $"{_apiUrl}/v1/text-to-speech/{_voiceId}{stream}?optimize_streaming_latency={LatencyOptimization}";
        var request = UnityWebRequest.Post(url, json);
        var downloadHandler = new DownloadHandlerAudioClip(url, AudioType.MPEG);
        if (Streaming) {
            downloadHandler.streamAudio = true;
        }
        request.uploadHandler = uH;
        request.downloadHandler = downloadHandler;
        request.SetRequestHeader("Content-Type", "application/json");
        request.SetRequestHeader("xi-api-key", _apiKey);
        request.SetRequestHeader("Accept", "audio/mpeg");
        yield return request.SendWebRequest();

        if (request.result != UnityWebRequest.Result.Success) {
            Debug.LogError("Error downloading audio: " + request.error);
            yield break;
        }
        AudioClip audioClip = downloadHandler.audioClip;
        AudioReceived.Invoke(audioClip);
        request.Dispose();
    }

    [Serializable]
    public class TextToSpeechRequest {
        public string text;
        public string model_id; // eleven_monolingual_v1
        public VoiceSettings voice_settings;
    }

    [Serializable]
    public class VoiceSettings {
        public int stability; // 0
        public int similarity_boost; // 0
        public float style; // 0.5
        public bool use_speaker_boost; // true
    }
}

How to use it

Once you have the script attached to a GameObject, you first have to set the API key and the voice ID. You can find both in your ElevenLabs account. Then, from any other script, you can invoke the GetAudio method to get and play the AudioClip through the AudioReceived event.

For example, here it is a test “client” script:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
public class TestElevenLabsUI : MonoBehaviour
{

    public Button sendButton;
    public InputField inputField;
    public ElevenlabsAPI tts;

    void Start()
    {
        // Add the PlayClip handler to the ElevenLabsAPI script
        tts.AudioReceived.AddListener(PlayClip);

        // Add the Button's onClick handler
        sendButton.onClick.AddListener( () => {
            tts.GetAudio(inputField.text);
            inputField.text = "";
        });
    }

    public void PlayClip(AudioClip clip)
    {
        AudioSource.PlayClipAtPoint(clip, Camera.main.transform.position);
    }
}

This example script uses a button and an input field. When the button is pressed, the text in the input field is sent to the ElevenLabs API script. When the AudioClip is ready, the ElevenLab script will trigger the AudioReceived event, and the PlayClip method will be invoked.
